VENOM-2.800 AE

ANNIVERSARY EDITION

2-channel power amplifier
AB Class.
Rated power 4Ω (RMS), W: 300 x 2.
Rated power 2Ω (RMS), W: 550 x 2.
Rated power 1Ω (RMS), W: 800 x 2.
Rated power (bridge) 4Ω (RMS), W: 1000 x 1.
Rated power (bridge) 2Ω (RMS), W: 1600 x 1.
Input sensitivity: 6-0.2V
LPF (low-pass filter) filter: 50HZ-4kHz, 500Hz-20kHz (x10)
HPF (high-pass filter) filter: 20HZ-5kHz, 200Hz-20kHz (x10)
Frequency range: 20Hz — 20kHz.
Signal/noise ratio: 97dB.
Harmony distortion coefficient: 0.05%.
Working voltage: 9-15V
External fuse rating: 200A
Dimensions: 450 x 158 x 56 mm.

User manual

EAN: 4680136864262
