VENOM-CL5X

SIGNATURE EDITION
Manufactured according to technical specifications and
under the control of AurA Sound Equipment
Sincerely,
technical director Lysenko A.V.

5.25″ (13cm) speaker system.
Coaxial, 2-way.

Rated power: 61W
Maximum power: 101W
Frequency range: 60Hz – 20kHz
Resistance: 4 ohms
Sensitivity (1W/1m): 86dB
Total quality factor (Qts): 1.104
Equivalent volume (Vas): 3.23L
Installation depth: 59.5mm

Midwoofer:
Steel stamped basket
Coated paper diffuser
Butyl rubber suspension
High temperature 1″ (25.4mm) voice coil
Nickel plated blade terminals
Metal protective grills

Tweeter:
3/4″ (20mm) dome silk HF
Liquid cooled neodymium magnet
Variable HF tilt angle
Overload protection

Crossover:
High quality film capacitor
Roll-off slope 6 dB/octave
Tweeter overload protection circuit
