RHL-LD03

Line driver/ Hi-Low signal converter. 6 channel output (including 2 subwoofer channels).
4 Channel RCA input or 4 channel hi-input (speaker level).
Active input level control.
Signal summing HP/LP to full frequency range signal or regular mode.
5 channel output level control (up to 7V).
Low distortion and low noise.
Remote output signal in h-level input mode (Auto on).
Remote input signal in RCA input mode.
Nickel plated RCA connectors.

Signal to noise ratio: >80dB (IHF, A-weighting)
Frequency response: 20Hz-20kHz (±3dB)
Max. output signal: 7V
Total harmonic distortion: <0.05%
Input sensitivity (RCA input): 2V
Input sensitivity (High level): 10V
Input impedance: 10 kOhm
Power supply voltage: 10.5 — 16V negative ground
Item sizes: 115.0 x 102.0 x 24.0mm

EAN: 4627107218129
